AArch64 MP+dmb.sy+pos-data-wsi-rfi-ctrl
"DMB.SYdWW Rfe PosRR DpDatadW Wsi Rfi DpCtrldR Fre"
Cycle=Rfi DpCtrldR Fre DMB.SYdWW Rfe PosRR DpDatadW Wsi
Relax=
Safe=Rfi Rfe Fre Wsi PosRR DMB.SYdWW DpDatadW DpCtrldR
Prefetch=0:x=F,0:y=W,1:y=F,1:x=T
Com=Rf Fr
Orig=DMB.SYdWW Rfe PosRR DpDatadW Wsi Rfi DpCtrldR Fre
{
0:X1=x; 0:X3=y;
1:X1=y; 1:X4=z; 1:X8=x;
}
P0 | P1 ;
MOV W0,#1 | LDR W0,[X1] ;
STR W0,[X1] | LDR W2,[X1] ;
DMB SY | EOR W3,W2,W2 ;
MOV W2,#1 | ADD W3,W3,#1 ;
STR W2,[X3] | STR W3,[X4] ;
| MOV W5,#2 ;
| STR W5,[X4] ;
| LDR W6,[X4] ;
| CBNZ W6,LC00 ;
| LC00: ;
| LDR W7,[X8] ;
Observed
z=2; y=1; x=1; 1:X7=1; 1:X6=2; 1:X2=0; 1:X0=1;
